DRAINAGE OF HIGHWAY PAVEMENTS IBD

Sinopse

This edition of Hydraulic Engineering Circular No. 12 incorporates new design charts and procedures developed from laboratory tests of interception capacities and efficiencies of highway pavement drainage in- lets. A chart for the solution of the kinematic wave equation for overland flow and a new chart for the solution of Manning?s equation for triangular channels are provided. Charts and procedures for using the charts are provided for 7 grate types, slotted drain inlets, curb- opening inlets, and combination inlets on grade and in sump locations. Charts, tables, and example problem solutions are included in the text where introduced and discussed.The text includes discussion of the effects of roadway geometry on pavement drainage, the philosophy of design frequency and design spread selection, storm runoff estimating methods, flow in gutters, pavement drainage inlets, factors affecting capacity and efficiency, and comparisons of interception capacity, median inlets, embankment inlets, and bridge deck inlets. Five appendixes are included with discussion of the development of rainfall intensity-duration-frequency curves and equations, mean velocity in a reach of triangular channel with unsteady flow, the development of gutter capacity curves for compound and parabolic roadway sections, and the development of design charts for grates of specific size and bar configuration.
